Jaylec 65-3130 Alternator

12V 90A replacement alternator for selected Subaru Forester, Impreza, Legacy, Liberty and Outback petrol models listed below. Features a 59mm five-rib pulley and 80mm mounting span. Check the chassis and year entries below.

Technical Specifications

• Brand: Jaylec
• Part number: 65-3130
• Voltage: 12V
• Rated output: 90A
• Adjuster hole: 1 x M8
• Pivot holes: 2 x 8.5 mm
• Adjuster-to-pivot centres: 175 mm
• Inside foot-to-foot / pivot-lug dimension: 80 mm
• Pulley diameter: 59 mm
• Pulley type: 5PV

Part Number Cross References

Match the original alternator number and physical specification before ordering.

• BXSU2001M, F042303007, LR1100-733, LR190-742, A002TB28911, A002TB2891ZC, A002TB2892, A002TB2991
• A002TB6291, A2TB28911, A2TB2891ZC, A2TB2892, A2TB2991, A2TB6291, 23700-AA31A, 23700-AA370
• 23700-AA37A, 23700-AA390, 23700-AA430

Vehicle Application List

• Subaru Forester SF/SG 2.0L petrol and 2.0 S Turbo, EJ202/EJ205, 1998–2002.
• Subaru Impreza GC/GD/GF/GG 2.0L EJ201 petrol and 2.0 WRX EJ205 turbo petrol, 1998–2007.
• Subaru Impreza GC/GF 1.6L EJ16 petrol, 1992–1998.
• Subaru Impreza GD 2.0 WRX STI EJ207 turbo petrol, 2001–2007.
• Subaru Impreza GG 2.5L EJ25/EJ251 petrol, 2002–2005.
• Subaru Liberty III BE/BH 2.0L EJ201 petrol and 2.5L EJ25 petrol, 1998–2003.
• Subaru Liberty Outback BH 2.5L EJ25 petrol, 2000–2003.
• Subaru Legacy/Outback 2.5L EJ25 petrol, 2000–2002.

Applications apply to the specified engine and alternator configuration. Compare the original unit number, electrical connection and pulley before ordering.

Related air filters: K&N 33-2154 is listed for the 2001 Outback 2.5L petrol. For the 2000 Forester 2.0L non-turbo, K&N lists 33-2154 for the 368 × 165mm airbox and 33-2232 for the 279 × 167mm airbox. Match the airbox size; these variants are not interchangeable.
