NZA1019X is a replacement engine auxiliary cooling radiator for selected Toyota Hiace H200 manual models fitted with an auxiliary radiator setup. It combines an aluminium core with plastic tanks.

Selected Vehicle Applications:

• Toyota Hiace H200/TRH201/TRH221 2.7L 2TR-FE petrol, manual, 17/19; auxiliary radiator required
• Toyota Hiace H200/KDH 3.0L 1KD-FTV diesel, manual, 17/19; auxiliary radiator required

Technical Specifications:

• Transmission: Manual
• Core Construction: Aluminium with plastic end tanks
• Core Dimensions: 268x350x26mm
• Hose Outlets: 31mm inlet, 31mm outlet

Note: Core measurements describe the cooling matrix only, excluding tanks and mounting brackets.

Cross-Reference Part Numbers:

• OEM: 16400-30190, 16400-30230
• Adrad: TOY111
• Koyorad: PL011570
• Repco: RAD1019X

Fitment Note:

This is an auxiliary radiator unit. Please confirm its mounting position, hose connections, and physical dimensions on your vehicle. It is not a replacement or substitute for the main engine radiator.

Always use the vehicle manufacturer’s specified coolant type and bleeding procedure when fitting. Inspect hoses, cap, and cooling fans as part of installation.

Warranty Details

Duration: 2 years or 50,000 kilometres (whichever happens first).
