Jaylec 65-6697 Alternator

24V 90A alternator for selected Renault Kerax 370, 410 and 450 trucks with the 10.8L DXi diesel engine. Features a 63mm five-rib pulley and 67mm mounting span.

Technical Specifications

• Brand: Jaylec
• Part number: 65-6697
• Voltage: 24V
• Rated output: 90A
• Adjuster hole: 1 x 8 mm
• Pivot holes: 2 x 10 mm
• Adjuster-to-pivot centres: 178 mm
• Inside foot-to-foot / pivot-lug dimension: 67 mm
• Pulley diameter: 63 mm
• Pulley type: 5PV

Part Number Cross References

Match the original alternator number and physical specification before ordering.

• A004TR5091ZT, A4TR5091, A4TR5091ZT, A4TR5092, A4TR5093, A4TR5991, 50 01 866 377, 50 10 480 765

Vehicle Application List

• Renault Kerax 370, 410 and 450 cab-chassis; 10.8L DXi diesel, from 2005; end year and exact charging configuration require confirmation
• Mack trucks with Renault 10.8L diesel engine, 2006–2009; confirm the exact Mack model and original alternator number.

Applications apply to the specified engine and alternator configuration. Compare the original unit number, electrical connection and pulley before ordering.
